AOC G2590VXQ User Manual

Installation
Do not place the monitor on an unstable cart, stand, tripod, bracket, or table. If the monitor falls, it can injure a
person and cause serious damage to this product. Use only a cart, stand, tripod, bracket, or table recommended by
the manufacturer or sold with this product. Follow the manufacturer’s instructions when installing the product and
use mounting accessories recommended by the manufacturer. A product and cart combination should be moved
with care.
Never push any object into the slot on the monitor cabinet. It could damage circuit parts causing a fire or
electric shock. Never spill liquids on the monitor.
Do not place the front of the product on the floor.
If you mount the monitor on a wall or shelf, use a mounting kit approved by the manufacturer and follow the kit
instructions.
Leave some space around the monitor as shown below. Otherwise, air-circulation may be inadequate hence
overheating may cause a fire or damage to the monitor.
See below the recommended ventilation areas around the monitor when the monitor is installed on the wall or on
the stand:
Installed with stand
Leave at lease this space
around the set
10cm
4 英寸
10cm
4 英寸
30cm
11 7/8
英寸
10cm
4 英寸
6

AOC G2590VXQ Specifications

General

3D	-
Panel type	TN
Color depth	8 bit
Pixel pitch	0.2832 x 0.2832 mm
Screen shape	Flat
Backlight type	W-LED
Display surface	Matt
Pixel frequency	165 MHz
Display diagonal	24.5 \
Display technology	LED
Native aspect ratio	16:9
Vertical scan range	30 - 76 Hz
Maximum refresh rate	75 Hz
Horizontal scan range	30 - 83 kHz
Viewable size, vertical	302.62 mm
Viewing angle, vertical	160 °
Contrast ratio (dynamic)	20000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	543.74 mm
Viewing angle, horizontal	170 °
Digital vertical frequency	- Hz
Digital horizontal frequency	- kHz
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
HDMI version	1.4
DisplayPort version	1.2
Headphone connectivity	3.5 mm
RMS rated power	4 W
Cables included	AC, Audio (3.5mm), DisplayPort, HDMI, VGA
HDMI cable length	1.8 m
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (standby)	0.5 W
Power consumption (typical)	25 W
Pivot angle	1 - 90 °
Tilt angle range	-3.5 - 21.5 °
Number of OSD languages	16
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), CZE, DEU, DUT, ENG, ESP, FIN, FRE, ITA, JPN, KOR, POL, POR, RUS, SWE
AMD FreeSync type	FreeSync
AMD FreeSync refresh rate range	30 - 75 Hz
Recyclable packaging material	100 %
Mean time between failures (MTBF)	50000 h
Certification	ISO
Product color	Black
Heavy metals free	Hg (mercury)
Market positioning	Gaming
Package type	Box
Package depth	173 mm
Package width	627 mm
Package height	417 mm
Package weight	6620 g
Sustainability certificates	RoHS
Operating altitude	0 - 5000 m
Non-operating altitude	5000 - 12192 m
Storage temperature (T-T)	-25 - 55 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 93 %
Operating relative humidity (H-H)	10 - 85 %
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (with stand)	179.5 mm
Height (with stand)	419.8 mm
Weight (with stand)	4300 g
Depth (without stand)	78.2 mm
Width (without stand)	558.6 mm
Height (without stand)	- mm
Weight (without stand)	- g
