Color Setup
1. Press MENU-button to display menu.
2. Press Left or Right to select (Color Setup), and press MENU-button to enter.
3. Press Left or Right to select submenu, and press MENU-button to enter.
4. Press Left or Right to adjust.
5. Press AUTO-button to exit
.
Color Temp.
Warm Recall Warm Color Temperature from EEPROM.
Normal Recall Normal Color Temperature from EEPROM.
Cool Recall Cool Color Temperature from EEPROM.
sRGB Recall SRGB Color Temperature from EEPROM.
User
Red Red Gain from Digital-register
Green Green Gain Digital-register.
Blue Blue Gain from Digital-register
DCB Mode
Full Enhance on or off Disable or Enable Full Enhance Mode
Nature Skin on or off Disable or Enable Nature Skin Mode
Green Field on or off Disable or Enable Green Field Mode
Sky-blue on or off Disable or Enable Sky-blue Mode
AutoDetect on or off Disable or Enable AutoDetect Mode
DCB Demo On or off Disable or Enable Demo
25

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the AOC G2590VXQ and is the answer not in the manual?

AOC G2590VXQ Specifications

General IconGeneral
3D-
Panel typeTN
Color depth8 bit
Pixel pitch0.2832 x 0.2832 mm
Screen shapeFlat
Backlight typeW-LED
Display surfaceMatt
Pixel frequency165 MHz
Display diagonal24.5 \
Display technologyLED
Native aspect ratio16:9
Vertical scan range30 - 76 Hz
Maximum refresh rate75 Hz
Horizontal scan range30 - 83 kHz
Viewable size, vertical302.62 mm
Viewing angle, vertical160 °
Contrast ratio (dynamic)20000000:1
Contrast ratio (typical)1000:1
Display number of colors16.78 million colors
Viewable size, horizontal543.74 mm
Viewing angle, horizontal170 °
Digital vertical frequency- Hz
Digital horizontal frequency- kHz
Display brightness (typical)250 cd/m²
Supported graphics resolutions1920 x 1080 (HD 1080)
HDMI version1.4
DisplayPort version1.2
Headphone connectivity3.5 mm
RMS rated power4 W
Cables includedAC, Audio (3.5mm), DisplayPort, HDMI, VGA
HDMI cable length1.8 m
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Energy efficiency scaleA to G
Power consumption (standby)0.5 W
Power consumption (typical)25 W
Pivot angle1 - 90 °
Tilt angle range-3.5 - 21.5 °
Number of OSD languages16
Panel mounting interface100 x 100 mm
On Screen Display (OSD) languagesCHI (SIMPL), CHI (TR), CZE, DEU, DUT, ENG, ESP, FIN, FRE, ITA, JPN, KOR, POL, POR, RUS, SWE
AMD FreeSync typeFreeSync
AMD FreeSync refresh rate range30 - 75 Hz
Recyclable packaging material100 %
Mean time between failures (MTBF)50000 h
CertificationISO
Product colorBlack
Heavy metals freeHg (mercury)
Market positioningGaming
Package typeBox
Package depth173 mm
Package width627 mm
Package height417 mm
Package weight6620 g
Sustainability certificatesRoHS
Operating altitude0 - 5000 m
Non-operating altitude5000 - 12192 m
Storage temperature (T-T)-25 - 55 °C
Operating temperature (T-T)0 - 40 °C
Storage relative humidity (H-H)5 - 93 %
Operating relative humidity (H-H)10 - 85 %
Harmonized System (HS) code85285210
Weight and Dimensions IconWeight and Dimensions
Depth (with stand)179.5 mm
Height (with stand)419.8 mm
Weight (with stand)4300 g
Depth (without stand)78.2 mm
Width (without stand)558.6 mm
Height (without stand)- mm
Weight (without stand)- g
