AOC I2369Vm Service Manual

68
R908,R911 061G1206103-JF
RST CHIPR 10KOHM +-5% 1/4W
FENGHUA
061G1206103-JT
RST CHIPR 10KOHM -5% 1/4W TZAI
YUAN
2nd source
R913 061G1206109-JF
RST CHIPR 1 OHM +-5% 1/4W 1206
FENGHUA
061G1206109-JT CHIPR 1206 1 OHM - 5% 1/4W 2nd source
R812 061G12062007FF
RST CHIPR 0.2 OHM +-1% 1/4W
FENGHUA
R923 061G1206221-JF
RST CHIPR 220 OHM +-5% 1/4W
FENGHUA
061G1206221-JT
RST CHIPR 220 OHM -5% 1/4W TZAI
YUAN
2nd source
R900,R901,R902 061G1206624-JF
RST CHIPR 620 KOHM +-5% 1/4W
1206 FENGHUA
061G1206624-JT
RST CHIPR 620 KOHM -5% 1/4W
TZAI YUAN
2nd source
R817 061G1206681-JF
RST CHIPR 680 OHM +-5% 1/4W 1206
FENGHUA
061G1206681-JT RST CHIPR 680 OHM -5% 1/4W 2nd source
C812 065G080510131J---F
MLCC 0805 100pF +-5% 50V NPO
FENGHUA
065G080510131J---Y
MLCC 0805 100pF -5% 50V NPO
YAGEO
2nd source
C906,C914,C923 065G080510232K---F
MLCC 0805 1000pF +-10% 50V X7R
FENGHUA
065G080510232K---Y
MLCC 0805 1000pF -10% 50V X7R
YAGEO
2nd source
C802,C915 065G080510332K---F
MLCC 0805 10nF +-10% 50V X7R
FENGHUA
065G080510332K---Y
MLCC 0805 10nF -10% 50V X7R
YAGEO
2nd source
C814,C912,C924,C926 065G080510432K---F
MLCC 0805 0.1uF +-10% 50V X7R
FENGHUA
065G080510432K---Y
MLCC 0805 0.1uF -10% 50V X7R
YAGEO
2nd source
C813 065G080527131J---Y
MLCC 0805 270P 50V NP0 +/-5%
YAGEO
065G080527131J---F
MLCC 0805 270P 50V NP0 /-5%
FENGHUA
2nd source
C807 065G080533332K---F MLCC 0805 33nF +-10% 50V X7R

AOC I2369Vm Specifications

General

3D	No
Pixel pitch	0.265 x 0.265 mm
Aspect ratio	16:9
Screen shape	Flat
Backlight type	W-LED
Display surface	-
Pixel frequency	170 MHz
Display diagonal	23 \
Display technology	LED
Vertical scan range	50 - 76 Hz
Maximum refresh rate	60 Hz
Horizontal scan range	30 - 83 kHz
Viewable size, vertical	286.74 mm
Contrast ratio (dynamic)	20000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	509.76 mm
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
HDCP	Yes
HDMI version	1.4
DisplayPort version	1.1
Headphone connectivity	3.5 mm
Tilt angle range	-3 - 21 °
Cable lock slot type	Kensington
Number of OSD languages	16
Panel mounting interface	75 x 75 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), CZE, DEU, DUT, ENG, ESP, FIN, FRE, ITA, JPN, KOR, POL, POR, RUS, SWE
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Annual energy consumption	29 kWh
Power consumption (standby)	0.5 W
Power consumption (typical)	25 W
Mean time between failures (MTBF)	50000 h
Feet color	Black/Silver
Certification	GOST
Product color	Black, Silver
Front bezel color	Silver
Heavy metals free	Hg (mercury), Pb (lead)
Market positioning	Home
Cables included	AC, HDMI, VGA
HDMI cable length	1.5 m
Power cable length	1.2 m
Package type	Box
Package depth	138 mm
Package width	603 mm
Package height	467 mm
Package weight	5480 g
Sustainability certificates	RoHS, ENERGY STAR
Operating altitude	0 - 5000 m
Non-operating altitude	0 - 12192 m
Storage temperature (T-T)	-25 - 55 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 93 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth (with stand)	204 mm
Height (with stand)	398 mm
Weight (with stand)	3760 g
Depth (without stand)	44.9 mm
Width (without stand)	531.4 mm
Height (without stand)	326.5 mm
Weight (without stand)	- g
