69
FENGHUA
065G080533332K---Y
MLCC 0805 33nF -10% 50V X7R
YAGEO
2nd source
C927 065G080547332K---F
MLCC 0805 47nF +-10% 50V X7R
FENGHUA
065G080547332K---Y
MLCC 0805 47nF -10% 50V X7R
YAGEO
2nd source
C804,C810,C811 065G080547432K---M
MLCC 0805 0.47uF +-10% 50V X7R
MURATA
065G080547432K---F
MLCC 0805 0.47uF -10% 50V X7R
FENGHUA
2nd source
C808 065G120610171J---Y
MLCC 1206 100pF +-5% 500V NPO
YAGEO
065G120610171J---A
MLCC 1206 100pF -5% 500V NPO
SAMSUNG
2nd source
C917,C928,C929 065G120622272K---F
MLCC 1206 2200pF +-10% 500V X7R
FENGHUA
065G1206222B2K---M
MLCC 1206 2200pF -10% 630V X7R
MURATA
2nd source
C916 065G120622272K---Y
MLCC 1206 2200pF +-10% 500V X7R
YAGEO
065G120622272K---F
MLCC 1206 2200pF -10% 500V X7R
FENGHUA
2nd source
U801 356G0700045
IC LED DRIVER PF7024 S SOP-16
Powerforest
PLCB441XAN4AI POWER BOARD FOR AI
CN901 006G--31500 EYELET
IC903 056G-158-10--T
IC DC/DC AS431AZTR-E1 TO-92
TO92RAK
056G-158-12
IC DC/DC KIA431A-AT/P TO-92
TO92RAK
2nd source
Q904 057G-530503--T
MOSFET 2SD1207T 2A/60V TO-92L
BLUE ROCKET
057G-761-16
TRA KTD1028 1A/50V TO-92L
KECCSEOU
2nd source
R915 061G-17222052T--TZ
RST CFR 22 OHM +-5% 1/4W TZAI
YUAN
061G-17222052T--XZ
RST CFR 22 OHM -5% 1/4W
XIANZHENG
2nd source
R906 061G152M10452T--SY
MOFR 100KOHM +-5% 2WS
SHUANGYU
