AOC I2369Vm Service Manual

70
R904 061G152M25152T--SY
RST MOFR 250 OHM +-5% 2WS
FUTABA
R924 061G152M43852T--SY
RST MOFR 0.43 OHM +-5% 2WS
FUTABA
061G152M43852T--HX RST MOF 0.43R 5% 2WS HX 2nd source
C911 065G--2K152-2T6921 CAP CER 1500pF K 2KV Y5P
065G--2K152-2T6213 CAP CER 1500PF K 2KV 2nd source
C805 065G500K4742HT CAP CER 470NF 10% 50V X7R TORCH
C816 065G517K102-2T6921
CAP CER 1000pF +-10% 500V Y5P
WANSHENG
C920 067G-2041022LT
EC 1000uF 20% 10V 10*12 2000Hr
LELON
067G-2041022KT
EC 1000uF 20% 10V 10*12 2000Hr
CHINSAN
2nd source
C925 067G-2046812KT CS CAP 680uF 10V 8*11 mm
067G-2046812LT CAP CS 680UF 20% 10V 8*11.5 2nd source
C809 067G-4153309LT
EC 33uF +-20% 100V 8*11.5 4000H
LELON
067G-4153309KT
EC 33uF -20% 100V 8*12 4000H
ELITE
2nd source
C801 067G215D3314KT
EC 330uF +-20% 25V 10*12 4000Hr
CHINSAN
C918,C919 067G215D6814KT
EC 680uF +-20% 25V 10*20 4000Hr
CHINSAN
067G215D6814LT
EC 680uF -20% 25V 10*20 4000Hr
LELON
2nd source
C922,C931 067G215S4713KT
EC 470uF +-20% 16V 10*13 4000Hr
CHINSAN
067G215S4713LT
EC 470uF -20% 16V 10*12.5 4000Hr
LELON
2nd source
C913 067G215Y4707KT 47uF 50V
067G215Y4707LT LOW ESR EC 47uF 50V M 6.3*11mm 2nd source
J810 071G--55--9--T FERRITE BEAD
FB801,FB802,FB901 071G--55-29 FERRITE BEAD
071G--55-29--X
BEAD 3.5*2.2*0.8 45R -25%
3BDR3522-453A ASET
2nd source
F801 084G--56--3--C
FUSE 3.15A 250V MST 3.15A 250V
CONQUER
F901,F902,F903 084G--56--5--C FUSE 5A 250V MST 5A 250V
084G--56--5--B FUSE 5A 250V SS-5-5A-AP 2nd source
ZD901 093G--39A6852T DIODE ZD DIODES MTZJ22B

AOC I2369Vm Specifications

General

3D	No
Pixel pitch	0.265 x 0.265 mm
Aspect ratio	16:9
Screen shape	Flat
Backlight type	W-LED
Display surface	-
Pixel frequency	170 MHz
Display diagonal	23 \
Display technology	LED
Vertical scan range	50 - 76 Hz
Maximum refresh rate	60 Hz
Horizontal scan range	30 - 83 kHz
Viewable size, vertical	286.74 mm
Contrast ratio (dynamic)	20000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	509.76 mm
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
HDCP	Yes
HDMI version	1.4
DisplayPort version	1.1
Headphone connectivity	3.5 mm
Tilt angle range	-3 - 21 °
Cable lock slot type	Kensington
Number of OSD languages	16
Panel mounting interface	75 x 75 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), CZE, DEU, DUT, ENG, ESP, FIN, FRE, ITA, JPN, KOR, POL, POR, RUS, SWE
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Annual energy consumption	29 kWh
Power consumption (standby)	0.5 W
Power consumption (typical)	25 W
Mean time between failures (MTBF)	50000 h
Feet color	Black/Silver
Certification	GOST
Product color	Black, Silver
Front bezel color	Silver
Heavy metals free	Hg (mercury), Pb (lead)
Market positioning	Home
Cables included	AC, HDMI, VGA
HDMI cable length	1.5 m
Power cable length	1.2 m
Package type	Box
Package depth	138 mm
Package width	603 mm
Package height	467 mm
Package weight	5480 g
Sustainability certificates	RoHS, ENERGY STAR
Operating altitude	0 - 5000 m
Non-operating altitude	0 - 12192 m
Storage temperature (T-T)	-25 - 55 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 93 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth (with stand)	204 mm
Height (with stand)	398 mm
Weight (with stand)	3760 g
Depth (without stand)	44.9 mm
Width (without stand)	531.4 mm
Height (without stand)	326.5 mm
Weight (without stand)	- g
