AOC I2369Vm Service Manual

71
21.51V/0.5W DO-34 SEMTECH
093G--3916352T
DIODE ZD TZX22B 22V/05W DO-35
VISHAY
2nd source
D903,D904 093G--6026T52T
DIODE RECTIFIER FR107 AO
1A/1000V TSC
093G--60964
Diode RECTIFIER PS1010R T/B 1A
1000V DO-41 PANJIT
2nd source
D907 093G--6452452T
DIODE SWITCHING 1N4148-B4006
0.2A 100V DO-35 SEMTECH
FB902,J801,J802,J803,J8
04,J805,J806,J807,J808,
J809,J812,J815,J816,J90
1,J902,J903,J905,J906,J
907,J908,J910,J911,J912
,J921
095G--90-23 JUMPER WIRE
E715 715G4744P02004001M
Power PCB FR1 SS 195*132*1.6MM 2
联板 闽威
715G4744P02004001S
Power PCB FR1 SS 195*132*1.6MM 2
联板 三照
2nd source
715G4744P02004001H
Power PCB FR1 SS 195*132*1.6MM 2
联板 汇和
2nd source
GND1 Q09G601500100100RJ
料带端子
Q01G700100A003 Hand_screw
Q12G6082--1 FOOT PAD
Q15G1351301 Main_frame
Q15G1405101 Hinge_bkt
Q15G1406101 Base_bkt
Q16G0001020096
泡棉
Q37G0307011 Hinge
Q40G-58162435A P/N LABEL FOR MANUAL PE BAG
Q40G000161518A
CARTON LABEL(70*40mm)卷状
Q40G0001624-4A PALLET LABEL
Q40G0003615A80 QC PASS LABEL
Q45G2010M0201A pe bag for manual
Q45G8801607100 PE BAG
Q45G9901609408 EPE BAG
Q52G1501527 Antistatic tape
Q52G1801MNT038 mylar
Q52G1801MNT176 mylar_btm
Q52G1801MNT177 mylar_top

AOC I2369Vm Specifications

General

3D	No
Pixel pitch	0.265 x 0.265 mm
Aspect ratio	16:9
Screen shape	Flat
Backlight type	W-LED
Display surface	-
Pixel frequency	170 MHz
Display diagonal	23 \
Display technology	LED
Vertical scan range	50 - 76 Hz
Maximum refresh rate	60 Hz
Horizontal scan range	30 - 83 kHz
Viewable size, vertical	286.74 mm
Contrast ratio (dynamic)	20000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	509.76 mm
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
HDCP	Yes
HDMI version	1.4
DisplayPort version	1.1
Headphone connectivity	3.5 mm
Tilt angle range	-3 - 21 °
Cable lock slot type	Kensington
Number of OSD languages	16
Panel mounting interface	75 x 75 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), CZE, DEU, DUT, ENG, ESP, FIN, FRE, ITA, JPN, KOR, POL, POR, RUS, SWE
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Annual energy consumption	29 kWh
Power consumption (standby)	0.5 W
Power consumption (typical)	25 W
Mean time between failures (MTBF)	50000 h
Feet color	Black/Silver
Certification	GOST
Product color	Black, Silver
Front bezel color	Silver
Heavy metals free	Hg (mercury), Pb (lead)
Market positioning	Home
Cables included	AC, HDMI, VGA
HDMI cable length	1.5 m
Power cable length	1.2 m
Package type	Box
Package depth	138 mm
Package width	603 mm
Package height	467 mm
Package weight	5480 g
Sustainability certificates	RoHS, ENERGY STAR
Operating altitude	0 - 5000 m
Non-operating altitude	0 - 12192 m
Storage temperature (T-T)	-25 - 55 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 93 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth (with stand)	204 mm
Height (with stand)	398 mm
Weight (with stand)	3760 g
Depth (without stand)	44.9 mm
Width (without stand)	531.4 mm
Height (without stand)	326.5 mm
Weight (without stand)	- g
