AOC L42H861 Service Manual

42″LCD TV AOC L42H861
75
C412
065T0603102 32
CHIP 1000PF 50V X7R
C450
065T0603102 32
CHIP 1000PF 50V X7R
C454
065T0603102 32
CHIP 1000PF 50V X7R
C457
065T0603102 32
CHIP 1000PF 50V X7R
C652
065T0603102 32
CHIP 1000PF 50V X7R
C653
065T0603102 32
CHIP 1000PF 50V X7R
C657
065T0603102 32
CHIP 1000PF 50V X7R
C665
065T0603102 32
CHIP 1000PF 50V X7R
C667
065T0603102 32
CHIP 1000PF 50V X7R
C670
065T0603102 32
CHIP 1000PF 50V X7R
C452
065T0603103 12
CHIP 0.01UF 16V X7R
C620
065T0603103 12
CHIP 0.01UF 16V X7R
C621
065T0603103 12
CHIP 0.01UF 16V X7R
C655
065T0603103 12
CHIP 0.01UF 16V X7R
C511
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C510
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C509
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C508
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C507
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C512
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C513
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C514
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C515
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C516
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C517
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C603
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C604
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C605
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C606
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C607
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C608
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C444
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C445
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C446
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C447
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C4A9
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C4B1
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C4B2
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C4B3
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C4B4
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C4B5
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C4B6
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C4B7
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C4C2
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C4C4
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C4D1
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C501
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C502
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C503
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C504
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C505
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C506
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C702
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C705
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C711
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C713
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C721
065T0603104 12
MLCC 0603 0.1UF K 16V X7R

AOC L42H861 Specifications

General

3D	No
Power LED	Yes
Pixel pitch	0.4845 x 0.4845 mm
Vertical scan range	60 - 75 Hz
Headphone connectivity	3.5 mm
Digital vertical frequency	56 - 75 Hz
Digital horizontal frequency	31.5 - 60 kHz
Response time	8 ms
Display diagonal	42 \
Display brightness	500 cd/m²
Display technology	LCD
Native aspect ratio	16:9
Contrast ratio (dynamic)	6000:1
Contrast ratio (typical)	1500:1
Display number of colors	16.78 million colors
Viewing angle, horizontal	176 °
Supported graphics resolutions	1920 x 1080 (HD 1080)
Package depth	251.46 mm
Package width	1155.7 mm
Package height	807.72 mm
Package weight	25600 g
Certification	FCC, cULus, RoHS, TUV-S
Audio (L/R) out	1
SCART ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
S-Video inputs quantity	2
Sustainability certificates	ENERGY STAR
Product color	Black
LED indicators	Y, Stand-by
Panel mounting interface	400 x 200 mm
Cables included	AC, VGA
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	250 W
RMS rated power	14 W
Tuner type	Analog
Analog signal format system	NTSC, PAL, PAL M, PAL N

Weight and Dimensions

Depth (with stand)	261.62 mm
Width (with stand)	1010.92 mm
Height (with stand)	688.34 mm
Depth (without stand)	99.06 mm
Height (without stand)	635 mm
