AOC L42H861 Service Manual

42″LCD TV AOC L42H861
76
C722
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C727
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C728
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C731
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C732
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C733
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C736
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C739
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C742
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C743
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C749
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C750
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C756
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C771
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C609
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C610
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C611
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C612
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C613
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C632
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C634
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C643
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C645
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C646
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C647
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C658
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C673
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C674
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C680
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C681
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C6B1
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C6B4
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C6B5
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C443
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C2B6
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C2B5
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C2B4
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C2A3
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C2A1
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C295
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C292
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C291
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C290
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C270
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C268
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C260
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C256
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C255
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C250
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C248
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C244
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C243
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C236
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C215
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C201
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C2B7
065T0603104 12
MLCC 0603 0.1UF K 16V X7R
C442
065T0603104 12
MLCC 0603 0.1UF K 16V X7R

AOC L42H861 Specifications

General

3D	No
Power LED	Yes
Pixel pitch	0.4845 x 0.4845 mm
Vertical scan range	60 - 75 Hz
Headphone connectivity	3.5 mm
Digital vertical frequency	56 - 75 Hz
Digital horizontal frequency	31.5 - 60 kHz
Response time	8 ms
Display diagonal	42 \
Display brightness	500 cd/m²
Display technology	LCD
Native aspect ratio	16:9
Contrast ratio (dynamic)	6000:1
Contrast ratio (typical)	1500:1
Display number of colors	16.78 million colors
Viewing angle, horizontal	176 °
Supported graphics resolutions	1920 x 1080 (HD 1080)
Package depth	251.46 mm
Package width	1155.7 mm
Package height	807.72 mm
Package weight	25600 g
Certification	FCC, cULus, RoHS, TUV-S
Audio (L/R) out	1
SCART ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
S-Video inputs quantity	2
Sustainability certificates	ENERGY STAR
Product color	Black
LED indicators	Y, Stand-by
Panel mounting interface	400 x 200 mm
Cables included	AC, VGA
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	250 W
RMS rated power	14 W
Tuner type	Analog
Analog signal format system	NTSC, PAL, PAL M, PAL N

Weight and Dimensions

Depth (with stand)	261.62 mm
Width (with stand)	1010.92 mm
Height (with stand)	688.34 mm
Depth (without stand)	99.06 mm
Height (without stand)	635 mm
