6. Control Remoto - mal funcionamiento
Control remoto - mal funcionamiento
Reemplace batería
Reemplace el control remot
o
¿Es anormal la IR board?
Si
No
Reemplace IR board
Reemplace main board
No
Si
No
Si
Use otros controles remotos, ¿fun
ciona?
Revise la batería del control remoto
si está
bien colocada o no tiene energía
39
41
Table of Contents
Default Chapter
1
Table of Contents
1
Important Safety Notice
2
Revision List
3
1 General Specification
4
2 Operating Instructions
6
The Use of Remote Control
6
To Use the Menus
7
How to Connect
14
Front Panel Control Knobs
16
3 Input/Output Specification
20
4 Mechanical Instructions
23
5 Repair Flow Chart
35
6 PCB Layout
42
Main Board
42
Power Board
46
Key Board
55
IR Board
56
7 Adjustment
57
ADC Adjustment
57
FW Upgrade
58
8 Block Diagram
59
9 Schematic Diagram
60
Main Board
60
Power Board
77
Key Board
82
IR Board
84
10 Exploded View
86
11 BOM List
92
