AOC LC32D1322 User Manual

92
11. BOM List
Note: The parts information listed below are for reference only, and are subject to change without notice.
Please go to http://cs.tpv.com.cn/hello1.asp
for the latest information.
LC32D1322 E32CA2NSW3B13NX
Location Part No. Description Remark
705TXCBCPD4 705 ASS’Y FOR BRAZIL packing
001G6021 1 SCREW
011G6036 1 SPACER SUPPORT SCC-24
045G 77500 BARCODE RIBBON
045G 77501 BAR CODE RIBBON x300x75
050G 600 1 W WHITE STRAP (1G004991)
052G 1185 MIDDLE TAPE (Y1200141)
052G 1186 SMALL TAPE
052G 2191 A PAPER TAPE
052G 2191 A PAPER TAPE
SP01 078G0120 27 Y SPEAKER 16 OHM 12W 125X32.5 - NO
ECN601 095G8013 4X 70 HARNESS 4P-B&R+B&W 800+400mm LCDXXTF1040
ECN701 095G801313XY11 HARNESS 13P-13P 200mm
ECN904 095G801414XX06 HARNESS 13P-14P 280mm
098GRABD3NEACR REMOTE AOC RC2444204/01
0M1G 930 8 47 CR3 SCREW 3x8
0M1G 940 6120 SCREW 4x6
0M1G 940 10 47 CR3 SCREW 4.0x10
0M1G 940 14 47 CR3 SCREW 4x14
0M1G1730 8120 SCREW 3x8
0M1G1740 14225 CR3 SCREW
0Q1G 940 14 47 CR3 SCREW
0Q1G 940 16 47 CR3 SCREW 4x16
0Q1G 940 25 47 CR3 SCREW
0Q1G1030 6120 SCREW 3x6
E08901 389G424A15N0IS AC POWER CORD 1500mm 2nd source
ECN409 395G176H30NX05 FFC CABLE 30P 530mm 1.0MM
ECN409 395G176W30NX05 FFC CABLE 30P 530 1.0MM 2nd source
ECN407 395G801413LY20 HARNESS 13P(2008)-5P+4P(1253) 700/800mm
705TXCCK011 Base Screw Ass'y
0Q1G 940 25 47 CR3 SCREW
Q45G 76 28NV2 R PE BAG FOR BASE SCREW sz02742
X40G0001624 2A Label for screw pe bag
750TAU315X4342N000 LCD T315XW04 V384 SZ AUO 2nd source
A15T0282201CKD BKT_VESA_BTM
A33T0788ADTB1L0100 Key cover
A33T0789AFL 1L0100 Key button
A34T1580ADT0EK0100 REAR COVER
P34T0681 GM 1L0200 base
P34T0682 GM 1L0300 COVER
P34T0683 GM 1L0100 BASE HINGE_COVER
P52G180105200000HB INSULATING SHEET
Q11G5052 1 STRING
