LE32D1322
Item Description
1 BEZEL
2 REAR_COVER
3 LENS IR
4 LENS LED
5 KEY
6 KEY_FRAME
7 STAND
8 BASE
9 AC COVER
10 COVER_STAND
11 BKT_STAND
12 BKT_MID
13 BKT_IO
14 BKT_POWER_BTM
15 FOOT PAD
Item Part No. Description Q’ty
16 INSULATING SHEET 18 0Q1G1030 8120 SCREW (IR BOARD-BEZEL) 1
17 SPONGE 19 0Q1G 330 8120 SCREW (BKT_MID-PANEL-BEZEL) 8
26 KEY BOARD 20 0M1G1730 8120
SCREW (BKT_POWER_BTM-PANEL/BKT_STAND-PANEL/
BKT_IO-PANEL/MAIN BOARD-PAENL/POWER BAORD-PAENL)
15
27 POWER BOARD 21 0M1G 940 6 47 CR3
SCREW (AC COVER-BKT_POWER_BTM/BKT_POWER_BTM-PAENL/
REAR COVER-BKT_STAND)
3
28 MAIN BOARD 22 0Q1G 330 8 47 CR3 SCREW (REAR COVER-HDMI) 1
29 IR BOARD 23 0M1G1740 12 47 CR3 SCREW (STAND-BKT_STAND) 4
30 PANEL 24 0Q1G 940 10 47 CR3 SCREW (REAR COVER-BEZEL) 14
31 SPEAKER 25 0Q1G 940 18 47 CR3 SCREW (STAND-BASE) 4
