LC32D1322
Item Description
1 BEZEL
2 KEY COVER
3 KEY BUTTON
4 KEY BOARD
5 LENS IR
6 POWER LENS
7 IR BOARD
8 SPEAKER
9 PANEL
10 BKT_AC_INLET
11 BKT_VESA
12 BKT_VESA
13 BKT_PCB_MAINBD_L
14 BKT_PANEL_L
15 BKT_PANEL_BTM
16 BKT_HOLDER
17 BKT_HOLDER
18 MAIN BOARD
Item Part No. Description Q’ty
19 BKT_IO 30 0Q1G1030 6120 SCREW (IR BOARD-BEZEL) 1
20 LABEL SIDE 31 001G6021 1 SCREW (SPEAKER-BEZEL) 4
21 BKT_PANEL_L 32 0Q1G 940 14 47 CR3 SCREW (PANEL-BEZEL) 2
22 POWER BOARD 33 0M1G 940 14 47 CR3 SCREW (BKT_AC_INLET-PANEL/BKT_PANEL_BTM-PANEL) 4
23 BKT_VESA_BTM 34 0M1G 940 6120 SCREW (PANEL BKT) 13
24 LABEL IO 35 0M1G1730 8120 SCREW (MAIN BOARD-PANEL BKT/POWER BOARD-PANEL BKT) 9
25 REAR COVER 36 0M1G1740 14225 CR3 SCREW (BASE HINGE_COVER-BKT_PANEL_L) 2
26 BASE HINGE_COVER 37 0M1G 940 10 47 CR3 SCREW (REAR COVER) 6
27 COVER 38 0Q1G 940 16 47 CR3 SCREW (REAR COVER) 10
28 BASE 39 0M1G 930 8 47 CR3 SCREW (REAR COVER-HDMI) 1
29 FOOT PAD 40 0Q1G 940 25 47 CR3 SCREW (BASE HINGE_COVER-COVER/BASE-BASE HINGE_COVER) 8
