LC42D1322
Item Description
1 BEZEL
2 BKT_HOLDER
3 KEY COVER
4 KEY BUTTON
5 KEY BOARD
6 IE LENS
7 LED LENS
8 IR BOARD
9 SPEAKER
10 PANEL
11 BKT_HOLDER
Item Part No. Description Q’ty
12 BKT_HOLDER 30 0Q1G 930 8 47 CR3 SCREW (BKT_HOLDER-PANEL-BEZEL) 2
13 BOLT 31 0Q1G1030 6120 SCREW (IR BOARD-BEZEL) 1
14 BKT_VESA 32 001G6021 1 SCREW (SPEAKER-BEZEL) 4
15 BKT_HOLDER 33 0Q1G 940 16 47 CR3 SCREW (BKT_HOLDER-PANEL) 4
16 BKT_HINGE 34 0M1G 940 6120 SCREW (BKT_VESA-PANEL) 4
17 MAIN BOARD 35 0M1G1730 8120 SCREW (BKT_HOLDER-PANEL/POWER BOARD-PANEL/MAIN BOARD-PANEL) 10
18 POWER BOARD 36 0M1G1740 8225 CR3 SCREW (BKT_HINGE-PANEL) 2
19 BKT_IO 37 0M1G1740 14120 SCREW (BKT_HINGE-BKT_HOLDER) 2
20 LABEL IO 38 0M1G1430 8 47 CR3 SCREW (BKT_HINGE-HINGE COVER) 2
21 HINGE COVER 39 0M1G 930 6 47 CR3 SCREW (DIE-CASTING-STAND) 2
22 STAND 40 0M1G1740 14225 CR3 SCREW (HINGE ASS'Y-STAND ASS'Y) 4
23 DIE-CASTING 41 0Q1G 130 8 47 CR3 SCREW (BKT_BASE-BASE) 6
24 BASE 42 Q01G6145 1 SCREW (STAND ASS'Y-BASE ASS'Y) 4
25 BKT_BASE 43 0Q1G 940 18 47 CR3 SCREW (REAR COVER-BEZEL) 10
26 FOOT PAD 44 0Q1G 940 30 47 CR3 SCREW (REAR COVER-PANEL) 4
27 BKT-VESA-BTM 45 0M1G 940 8 47 CR3 SCREW (REAR COVER-BKT_VESA/REAR COVER-BKT_HINGE) 4
28 REAR COVER 46 0M1G1430 8 47 CR3 SCREW (REAR COVER-HDMI) 1
29 LABEL SIDE 47 0Q1G 930 8 47 CR3 SCREW (REAR COVER-IO) 1
