AOC LE50A5340S/68 User Manual

48
AV_L_OUT#
AV_R_OUT#
R633
27K 1/16W 1%
Q602 MMBT3906
R634
100K 1%
+3.3V_Standby
R629
10K
R618 NC/10KR601 0.05R
R622 NC/0.05R R619 10K
R+
AMP_MUTE
POP
R630 4.7K
R0402
+
C450 100UF 16V
AMP_MUTE
L+
C630 330pF 50V
R620 NC/10 OHM 1/4W
R614
NC/100K 1/16W
C638
100N 50V
C639
1NF 50V
C620
NC/0.22uF 50V
R615 NC/100K 1/16W
POP
C626 330pF 50V
C617
NC/1NF 50V
C631 1UF 50V
C628
NC/0.22uF 50V
R626
10OHM1/16W
R621
10OHM1/16W
C636
NC/0.22uF 50V
C619
1NF 50V
R610 10OHM1/16W
C622 220NF 25V
C627 NC/1UF 50V
FB603 300R 4A
1 2
+
C640
100UF 35V
AC OFF POPO
C625
NC/0.22uF 50V
R612 10K
C618
100N 50V
C623 330pF 50V
C616 220NF 25V
R616
10OHM1/16W
+
C614
100UF 35V
+
C615
100UF 35V
R625
100OHM
CN601
CONN
1 2 3 4
5 6
R609 10OHM1/16W
C633 220NF 25V
C632 1UF 50V
C635 220NF 25V
R613
100OHM
R623
10OHM1/16W
C613 100N 50V
C637 330pF 50V
R611
10K
Q601
MMBT3904
C612
NC/1NF 50V
+5V_Normal
+5V_Normal
P24V PVDD
PVDD
PVDD
PVDD
AMP_MUTE Low: Mute disablde High: Mute enable
AMP_AUOUTR02 AMP_AUOUTL02
AUDIO_EN12
HS601 HEAT SINK
1 2
R-
R627
10K
L-
1.2A Max
OEM MODEL
Size Rev
Date
Sheet
of
TPV MODEL
PCB NAME
⿄⠍
T P V ( Top Victory Electronics Co . , Ltd. )
Key Component
㍀
䱨
⪰
㌾
㝍
A
B
812Wednesday , July 03, 2013
<
⿄⠍
>
AV_L_OUT# AV_R_OUT#
R628
10K
L604 22uH L601 22uH L602 22uH L603 22uH
C641 1UF 50V C634 1UF 50V C624 1UF 50V C629 1UF 50V
+5V_Standby
U601
AD52580-QG28NAR
SDZ
1
FAULTZ
2
LINP
3
LINN
4
GAIN0
5
GAIN1
6
AVCC
7
AGND
8
GVDD
9
PLIMIT
10
RINN
11
RINP
12
NC
13
PBTL
14
PVCCL
28
PVCCL
27
BSPL
26
OUTPL
25
PGND
24
OUTNL
23
BSNL
22
BSNR
21
OUTNR
20
PGND
19
OUTPR
18
BSPR
17
PVCC
16
PVCC
15
Thermal Pad
29
AMP_STB

AOC LE50A5340S/68 Specifications

General

Brand	AOC
Model	LE50A5340S/68
Category	LCD TV
Language	English
