11. BOM
Note: The following information of initial version BOM are only for reference of repair, not place the order as the
basis and are subject to change without notice. Please base on RSPL or Service BOM (http://cs.tpv.com.cn
),
thank you!
LE40A5340S/68 E40E21NCCKA12NX
Location Part No Description Remark
 036T 600 18119 GP NONWOVEN FABRTC 
ECN102 089G 17356CY01 RCA CABLE 100 
E089 089G204A15N IS AC POWER CORD 1500MM 
E08911 089G225A15N IS AC POWER CORD 1500MM 
 0M1G 130 5 47 CR3 SCREW 
 0M1G1030 6 47 CR3 SCREW 
 0M1G1730 6120 SCREW 3X6 
 0M1G1730 8120 SCREW 
 0M1G1740 8120 SCREW FOR STD/MF 42-D020715/42-D000649() 
 0Q1G 330 5 47 CR3 SCREW 
 0Q1G 930 6 47 CR3 SCREW 3X6 
 0Q1G1030 5120 SCREW 
SP01 378G0110567CDN 6 OHM 11W 132X34MM 0 UNIT 
SP01 378G0110567YDN 6 OHM 11W 146X34X41.9MM 0 UNIT 2nd Source
ECN104 389G017356GY09 AUDIO CABLE 100MM 
 392GB1TA1A362H BATTERY 1.5V 2P R03-B500-01S 
ECN701 395G801314LC19 HARNESS 14P-14P 550MM 2nd Source
ECN701 395G801314RC19 HARNESS 14P-14P 550MM 
ECN601 395G801404RD38 HARNESS 4P-B&R+B&W 650/340 
ECN401 395G801410DC41 HARNESS 10P-5P+2P 500/850 2nd Source
ECN401 395G801410RC41 HARNESS 10P-5P+2P 500/850 
ECN403 395G801851RC52 LVDS CABLE 51P-30P 400 
ECN403 395G801851XC52 LVDS CABLE 51P-30P 400 2nd Source
E09801 398GR08BEAC00G REMOTE AOC TS-Y108-103 ENGLISH 
 705TXE4121100X DFU ASS'Y 
 0M1G1740 18225 CR3 SCREW 4.0X20.0 
 Q45G2010M0101A PE BAG FOR MANUAL 
 Q45G88010TV08900X1 PROTECT BAG 
 X41G50MV61508A MANUAL LE40_50A5340S/68 AP SKD 
 040G 58162435A MANUAL P/N LABEL 
 X40G0001624 2A LABEL FOR SCREW PE BAG 
 705TXESC20700100SX MAIN BOARD ASS'Y 
 756TXECB01M001000X MAIN BOARD-CBPFE3QCX3 
SMTF-U402 100TAMVT010MTX MCU ASSY-056G2233 42 
 Z40G0002ALL01A OTHER LABEL 
CN401 033G380210B YH L CONNECTOR 10P 2.0 
C640 067G315M1016KV EC 100UF 20% 35V 8*7 
C615 067G315M1016KV EC 100UF 20% 35V 8*7 
CN104 088G 30288C PHONE JACK 3P GREEN - 1 1 
CN103 088G 78G113ACL RCA JACK R/A 3P BLACK H=10.5 
CN107 088G 78G134ACL RCA JACK R/A 6P G/BL/R 1*3 H=10.5 
CN101 088G302C5B1ACL PHONE JACK R/A 5P BLACK H=6.2 
CN106 088G352F6B3ACL USB A TYPE R/A 6P BLACK H=8.4 
CN105 088G353GFF1AXH D-SUB CONN 15P BLUE - R/A 10 
TU101 094G PALALL10L TUNER CHINA DT21WN-2-E 
CN601 311GW200A04ABX WAFER 2.0MM 4P 
CN403 311GW200C30ABL WAFER 2.0MM 2*15P 
CN403 311GW200C30ABX CONN 2.0MM 30P R/A 32MM 9.5MM 
