58
9.3 IR Board 715G6638R01000004K
R204
100R 1/10W 5%
R0603
VCC
U201 IRM-H938M3/TR2
GND
1
GND
2
OUT
3
VCC
4
IR
VCC
R201
15K 1/10W
081G 14 24 EL
OEM MODEL
Size Rev
Date
Sheet
of
TPV MODEL
PCB NAME
⿄⠍
T P V ( Top Victory Electronics Co . , Ltd. )
Key Component
㍀
䱨
⪰
㌾
㝍
A
A
22Monday , December 24, 2012
<
⿄⠍
>
R203 220 OHM 1/10W
LED_B LED_R
RED
BLUE
LED201 LED
1 23
4
R202 220 OHM 1/10W
CN201
CONN
1 2 3 4 5
67
356GS927057
033G8032 5F S B
C201 2.2UF 16V
