LM-522 Service Manual
30
9. White-Balance, Luminance adjustment
Approximately 30 minutes should be allowed for warm up before proceeding white balance adjustment.
Before started adjust white balance ,please setting the Chroma-7120 MEM. channel 1 to 6500 color, MEM. channel 2
to 7800 color ( our 6500 parameter is x = 313 ±10, y = 329 ±10, Y = 200 ±10 cd/m
2 ,
7200 parameter is x = 296 ±10, y =
311 ±10, Y = 200 ±10 cd/m
2
)
How to setting MEM.channel you can reference to chroma 7120 user guide or simple use “ SC” key and “ NEXT” key to
modify xyY value and use “ID” key to modify the TEXT description
Following is the procedure to do white-balance adjust
Press MENU button during 2 seconds along with press Power button will activate the factory mode, then MCU will do
AUTO LEVEL automatically. Meanwhile press MENU the OSD screen will located at left top of panel.
Bias adjustment :
set the contrast
to 70.
adjust the Bri ghtness
to 90.
Gain adjustment :
Move cursor to “-Factory-” and press MENU key
adjust 6500 color-temperature
Switch the chroma-7120 to RGB-mode (with press “MODE” button )
switch the MEM.channel to Channel 01 ( with up or down arrow on chroma 7120 )
The lcd-indicator on chroma 7120 will show x = 313 ±10, y = 329 ±10, Y = 200 ±5 cd/m
2
Adjust the RED on OSD window until chroma 7120 indicator reached the value R=100
adjust the GREEN on OSD, until chroma 7120 indicator reached G=100
adjust the BLUE on OSD, until chroma 7120 indicator reached B=100
repeat above procedure ( item 5,6,7) until chroma 7120 RGB value meet the tolence =100±2
Press Exit on OSD window to save the adjustment result
adjust 7800 color-temperature
Switch the chroma-7120 to RGB-mode (with press “MODE” button )
switch the MEM.channel to Channel 02 ( with up or down arrow on chroma 7120 )
The lcd-indicator on chroma 7120 will show x = 296 ±10, y = 311 ±10, Y = 200 ±5 cd/m
2
Adjust the RED on OSD window until chroma 7120 indicator reached the value R=100
adjust the GREEN on OSD, until chroma 7120 indicator reached G=100
adjust the BLUE on OSD, until chroma 7120 indicator reached B=100
repeat above procedure ( item 5,6,7) until chroma 7120 RGB value meet the tolence =100±2
Press Exit on OSD window to save the adjustment result
Turn the POWER-button off to on to quit from factory mode.
To Next Page
