LM-522 Service Manual
33
750LLC50P02 CPT 15" XP02 PANEL P 1 PCS
AM1L1740 10 47 SCREW P 4 PCS
AUPC560KB9
AUPC560KB4SMT AUDIO BOARD FOR T560K* M 1 PCS
CN202 33L801714A PIN HEADER 2*7P 2.0mm P 1 PCS
CN204 95G8014 3503 WIRE HARNESS P 1 PCS
U201 56L 616 1 TDA7496L BY ST P 1 PCS
AUPC560KB4AI AUDIO BOARD FOR T560K* M 1 PCS
C203 65L0805104 32 CHIP 0.1UF 50V X7R P 1 PCS
C204 65L0805474 22 CHIP 0.47UF 25V X7R 080 P 1 PCS
C206 65L0805474 22 CHIP 0.47UF 25V X7R 080 P 1 PCS
C211 65L0805101 31 CHIP 100PF 50V NPD 0805 P 1 PCS
C212 65L0805101 31 CHIP 100PF 50V NPD 0805 P 1 PCS
C213 65L0805104 32 CHIP 0.1UF 50V X7R P 1 PCS
R201 61L0603183 CHIP 18K OHM 1/10W P 1 PCS
R203 61L0603183 CHIP 18K OHM 1/10W P 1 PCS
R207 61L0603102 CHIPR 1K OHM +-5% 1/10W P 1 PCS
R208 61L0603102 CHIPR 1K OHM +-5% 1/10W P 1 PCS
R210 61L0603203 CHIPR 20K OHM+-5% 1/10W P 1 PCS
R211 61L0603203 CHIPR 20K OHM+-5% 1/10W P 1 PCS
715L1144 1 IO AUDIO BOARD P 1 PCS
C201 67L 3054713XT 470 uf 16v P 1 PCS
C202 67L 3054713XT 470 uf 16v P 1 PCS
C205 67L 3054713XT 470 uf 16v P 1 PCS
C207 67L 3054713XT 470 uf 16v P 1 PCS
C208 67L 3054713XT 470 uf 16v P 1 PCS
C209 67L 3091097XT 1.0uF +-20% 50V P 1 PCS
C210 67L 3091097XT 1.0uF +-20% 50V P 1 PCS
R212 61L 60220152T CFR 200 OHM +-5% 1/6W P 1 PCS
CBPC560KCNAA
AIC560KCNAA MAIN BOARD M 1 PCS
40G 45762412B CBPC LABEL P 1 PCS
C102 67L309V470 3 47UF 16V 85C P 1 PCS
C106 67L309V470 3 47UF 16V 85C P 1 PCS
C120 67L309V470 3 47UF 16V 85C P 1 PCS
C125 67L309V470 3 47UF 16V 85C P 1 PCS
C127 67L305V471 3K 470UF 16V P 1 PCS
C136 67L309V470 3 47UF 16V 85C P 1 PCS
C155 67L305V101 7K 100UF 50V P 1 PCS
