The descriptions for function control LEDS
Main Menu
Item
Main
Menu Icon
Sub Menu Item
Sub Menu
Icon
Description
Contrast
Contrast from Digital-register
Luminance
Brightness
Backlight Adjustment
Focus
Adjust Picture Phase to reduce Horizontal-Line
noise
Image Setup
Clock
Adjust picture Clock to reduce Vertical-Line noise.
H. Position
Adjust the horizontal position of the picture.
Image Position
V. Position
Adjust the vertical position of the picture.
Warm N/A Recall Warm Color Temperature from EEPROM.
Cool N/A Recall Cool Color Temperature from EEPROM.
User / Red
Red Gain from Digital-register.
User / Green
Green Gain Digital-register.
Color Temp.
User / Blue
Blue Gain from Digital-register.
Analog N/A Select input signal from analog source (D-Sub) Input Select
Digital N/A Select input signal from digital source (DVI)
H. Position
Adjust the horizontal position of the OSD.
V. Position
Adjust the vertical position of the OSD.
OSD Setup
OSD Timeout
Adjust the OSD timeout.
English N/A Set OSD display language to English.
Deutsch N/A Set OSD display language to German.
Français N/A Set OSD display language to French.
Español N/A Set OSD display language to Spain.
Italiano N/A Set OSD display language to Italian.
Language
Simplified Chinese N/A Set OSD display language to Simplified Chinese.
Information
Information N/A
Show the resolution, H/V frequency and input port
of current input timing.
Reset
Yes N/A
Clear each old status of Auto-configuration and set
the color temperature to Cool.
