Panel Power Circuit
Check MCU
OK
Change Q122
NG
Check Q122
if OK?
CHECK Q121
NG
Check the signal of
Q122 is high voltage.
OK
U401-Data Output
NG
OK
OK
Check MST51512 (U401)
Signal output Is the waveform
ok?
Replace MST51512 (U401) or
replace Main board.
If Main Board being replaced
please do the DDC – content
reprogrammed
