AOC M2470SWH User Manual

5
Power
The monitor should be operated only from the type of power source indicated on the label. If you are not sure
of the type of power supplied to your home, consult your dealer or local power company.
The monitor is equipped with a three-pronged grounded plug, a plug with a third (grounding) pin. This plug
will fit only into a grounded power outlet as a safety feature. If your outlet does not accommodate the three-wire
plug, have an electrician install the correct outlet, or use an adapter to ground the appliance safely. Do not defeat
the safety purpose of the grounded plug.
Unplug the unit during a lightning storm or when it will not be used for long periods of time. This will protect
the monitor from damage due to power surges.
Do not overload power strips and extension cords. Overloading can result in fire or electric shock.
To ensure satisfactory operation, use the monitor only with UL listed computers which have appropriate
configured receptacles marked between 100 - 240V ~, Min. 5A
The wall socket shall be installed near the equipment and shall be easily accessible.
For use only with the attached power adapter (Output 12Vdc) which have UL,CSA listed license (Only for
monitors with power adapter).

AOC M2470SWH Specifications

General

3D	No
Panel type	MVA
Pixel pitch	0.2715 x 0.2715 mm
Aspect ratio	16:9
Screen shape	Flat
Backlight type	W-LED
Display surface	-
Pixel frequency	165 MHz
Display diagonal	23.6 \
Surface hardness	3H
Display technology	LED
Maximum refresh rate	60 Hz
Supported video modes	1080p
Viewable size, vertical	293.32 mm
Contrast ratio (dynamic)	50000000:1
Contrast ratio (typical)	3000:1
Display number of colors	16.7 million colors
Display brightness (peak)	- cd/m²
Display diagonal (metric)	59.944 cm
Viewable size, horizontal	521.28 mm
Digital vertical frequency	50 - 76 Hz
Digital horizontal frequency	30 - 83 kHz
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	1920 x 1080 (HD 1080)
HDCP	Yes
HDMI version	1.4
Headphone connectivity	3.5 mm
USB Type-A downstream ports quantity	0
RMS rated power	2 W
Exterior finish type	Textured
Recyclable packaging material	100 %
Mean time between failures (MTBF)	50000 h
Certification	True
Product color	Black
Heavy metals free	Hg (mercury)
Market positioning	Home
Tilt angle range	-5 - 25 °
Cable lock slot type	Kensington
Number of OSD languages	16
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), CRO, CZE, DEU, DUT, ENG, ESP, FIN, FRE, ITA, JPN, KOR, POL, POR, RUS, SWE, TUR, UKR
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (off)	0.19 W
Power consumption (standby)	0.37 W
Power consumption (typical)	17.96 W
Package type	Box
Package depth	435 mm
Package width	620 mm
Package height	127 mm
Package weight	5210 g
VGA cable length	1.2 m
Cables included	AC, HDMI, VGA
HDMI cable length	1.5 m
Sustainability certificates	RoHS, EPEAT Silver, ENERGY STAR
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (with stand)	221 mm
Height (with stand)	400.4 mm
Weight (with stand)	3580 g
Depth (without stand)	78.2 mm
Width (without stand)	551.4 mm
Height (without stand)	396.9 mm
Weight (without stand)	- g
