Page #11 background image
9
Connecting the Monitor
Cable Connections In Back of Monitor and Computer:
4 531
2
6 5 1
7
27V3H Q27V3U27V3
7 4
5
1
1. Power
2. HDMI-1
3. HDMI-2
4. DisplayPort
5. Earphone
6. D-SUB
7. HDMI
Connect to PC
1. Connect the power cord to the back of the display rmly.
2. Turn o󰀨 your computer and unplug its power cable.
3. Connect the display signal cable to the video connector on the back of your computer.
4. Plug the power cord of your computer and your display into a nearby outlet.
5. Turn on your computer and display.
If your monitor displays an image, installation is complete. If it does not display an image, please refer Troubleshooting.
To protect equipment, always turn o󰀨 the PC and LCD monitor before connecting.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the AOC U27V3 and is the answer not in the manual?

AOC U27V3 Specifications

General IconGeneral
Screen Size27 inches
Panel TypeIPS
Refresh Rate60Hz
Response Time5 ms
Brightness350 cd/m²
Contrast Ratio1000:1
Aspect Ratio16:9
VESA Mount100x100mm
Viewing Angle178°/178°
PortsHDMI, DisplayPort
Resolution3840 x 2160 (4K UHD)
