AOC U27V4EA - General Specification (U27 V4 EA)

26
Panel
Model name U27V4EA
Driving system TFT Color LCD
Viewable Image Size 68.5cm diagonal
Pixel pitch 0.1554(H)mm x 0.1554(V) mm
Display Color
1.07B Colors
Others
Horizontal scan range 30-140kHz
Horizontal scan Size(Maximum) 596.736mm
Vertical scan range 23-75Hz
Vertical Scan Size(Maximum) 335.664mm
Optimal preset resolution 3840x2160@60Hz
Max resolution
3840x2160@60Hz
Plug & Play
VESA DDC2B/CI
Power Source 19Vdc,2.37A
Power Consumption
Typical(default brightness and contrast) 33W
Max. (brightness = 100, contrast =100) ≤ 48W
Standby mode
≤0.5W
Physical
Characteristics
Connector Type
HDMI/DP/Earphone out
Signal Cable Type
Detachable
Environmental
Temperature
Operating 0°~ 40°
Non-Operating -25°~ 55°
Humidity
Operating 10% ~ 85% (non-condensing)
Non-Operating 5% ~ 93% (non-condensing)
Altitude
Operating 0~ 5000 m (0~ 16404ft )
Non-Operating 0~ 12192m (0~ 40000ft )
