18
APPENDIX A:RJ-45 PIN SPECIFICATION
When connecting your 5/8-port 10/100M NWay Fast
Ethernet Switch to another switch, a bridge or a hub, a
modified crossover cable is necessary. Please review
these products for matching cable pin assignment.
The following diagram and tables show the standard RJ-
45 receptacle/connector and their pin assignments for the
switch-to-network adapter card connection, and the
straight / crossover cable for the Switch-to-
switch/hub/bridge connection.
RJ-45 Connector pin assignment
Contact Media Direct Interface Signal
1 TX + (transmit)
2 TX - (transmit)
3 Rx + (receive)
4 Not used
5 Not used
6 Rx - (receive)
7 Not used
8 Not used
The standard cable, RJ-45 pin assignment
