2-3 Install HDD on Supporter with slim ODD
2-3-1 Put slim ODD on the top side of supporter,
screw the position 1 and 2 with M2 screw first,
then screw position 3 and with M2 screw to fix
the slim ODD.
(Screwdriver torque : 0.7±0.1kgf.cm)
