AOX AOX-Q-005 User Manual

- 6 -
4.3 Option Specification
No.
Option scheme
Remark
1
Explosion-proof actuator（Exd ⅡCT5）
AOX-Q series
2
Water-proof actuator (IP68,10M,250HR)
AOX-Q series
3
Potentiometer unit
（
1K-10K
）
AOX-Q series
4
Proportion control unit (control signal 4-20mA DC/1-5V/1-10V)
AOX-Q series
5
Local control units (local control open/stop/close optional switch, local/remote
switch)
AOX-Q series
6
Travel 120°, 180°,270°
AOX-Q series
7
Direct current motor (24VDC)
AOX-Q series
8
Torque switch (SPDT× 2 250VAC 10A)
Except
AOX-Q-005/008/010
9
Electric current position sensor (output 4-20mA DC)
AOX-Q series
10
Self-reset when power failure
AOX-Q series
11
High temperature resistance actuator (-10℃～+100℃)
AOX-Q series
12
Low temperature resistance actuator (-40℃～+70℃)
AOX-Q series
13
Low speed actuator
AOX-Q series
5.Structure
Electric actuators is make up of the following parts
◎ Housing: including shell and base
◎ Drive parts: asynchronous motor
◎ Driving mechanism:double worm and clutch
◎ Ratio control parts:separate with the mechanical parts, easy to debug
◎ Torque switch and limit switch parts
◎ Opening detected and feedback parts.

AOX AOX-Q-005 Specifications

General

Brand	AOX
Model	AOX-Q-005
Category	Controller
Language	English
