aoyue Int732 - Product Description; Functions & Features

4
TheAoyue Int732 Game ConsoleRepairingSystemisa reworkingequipment
thatutilizesinfrared(IR)heatingtechnology,toprovidetopandbottomheatingto
the target components. It is equipped with a versatile board holder, Lead free
compatiblesolderIron,andsoftwareprofilecontrolofheatinginone sophisticated
package. It is designed for reworking doublesided, diverse technology printed
circuitboards(PCB)whichutilizestraditionalorleadfreesolder.
Thesystemisequipped withHigh poweredIRheatingelementscombined
with multiple types of operating mode to fit various task. Finally, the unique,
innovativedesignwithdigitalcontrolpaneloffersprecision,safety,andeaseofuse
tomeetallreworkingrequirements.
PRODUCT DESCRIPTION
● Complete Game Console Repairing System.Combines  large  area bottom
heater, high powered topheater andlead freecompatiblesolder ironin one
package.
● Threedifferenttypesofoperationtosuitedifferentneeds:
Type0–Forreballingorprebakingtheboard.Usesinternalsensors.
Type1–Allowsmanualcontrolofthereworkprocess.Usesexternalsensors.
Type2–Automatedreflowingprocessutilizingtheuserconfigurableprofile.
● ClosedLoopTemperatureControlwithThreeExternalSensors
—Sensorsattachedtotheboardallowsprecisetemperaturecontrolatboard
level minimizing damage to board due toinaccurate temperature settings or
overheating. Two sensors are used as temperature control and monitoring,
while  an  extra sensor is added  to  allow  additional monitoring of  other
temperaturesensitiveareasofthePCB.
● EnhancedTopandbottomheater
310x310mmeffectivebottomheatingarea.1500wattsofpreheatingpower
minimizesboardwarping.
60x60mmeffectivetopheatingarea.500wattsmaximumheatingpowerwith
variousnozzlestofitdifferentBGAsizes.
FUNCTIONS and FEATURES
13
OPERATING PROCEDURES
Note: Duringsegments13thetopheaterheatsupto75%ofthesettemperature
atthesesegments. Thisistoallowafaster rampupinpreparationforreflowfor
segments46.
1. Toentertype“2”operation.Select2attheinitialscreenthenpresstheselect
button.Thedisplaywouldchangeto“SlctProf 0”.Thissignifieswearenow
inthetype“2”mode.
2. We can then select which profile we would like to use by pressing the
increaseor decrease button. The numbershownat the bottomdisplay will
changecorrespondingtoyourselection.Therearethreestoredandselectable
profile.
3. To adjust the time and temperature profile of each segment press the
selectionbuttontwice.Thetopdisplaywillshowwhichsegment“SEG1” we
are currently adjusting. The middle display will show whether we are
adjustingthe“dur” (duration/Time)or“tEMP” (temperature).Thebottom
displayshowsthevaluewearecurrentlyadjusting.Itssuffix“t”signifieswe
areadjustingthetimeortemperatureforasuffix“C”.
4. Press the increase or decrease button to adjust the desired duration and
temperature. The set temperature is adjustable from 50 to 250 C and
duration5to200seconds.
5. Afterthedurationortemperatureissetpresstheselectionbuttontomoveto
the next segment. There are six segments available each with its own
durationandtemperaturesettings.Thedurationsettingssignifiesthetimeit
willtaketoreachoursettemperaturelevel.Forexample:ifsetdurationis50t
andtemperatureissetat100C.Thenassumingtheboardtemperatureis50C
whentheautomatedreworkisinitializedthesystemwouldgraduallyincrease
boardtemperatureby1 Degreepersecondsuchthat after 50 secondsthe
boardtemperaturewouldreach100C.
6. After we have set the segments of the profile we may begin automated
reworking. To start automationrepeatedly pressthe  selection button until
thedisplayshowstheword“Run Prof 0” (thebottomdisplaynumbershould
correspondtotheselectedprofile)thenpresstheincreasebutton.A3second
countdownwillcommencebeforeautomatedreworkingstarts.
