aoyue Int732 - Package Inclusion; Specifications; Operating Procedures

6
PACKAGE INCLUSION
Instruction
Manual
732MainStation
SolderingIron
SolderingIron
stand
SPECIFICATIONS*
PowerInput: Availablein110V21Amps/220V11Amps(Max)
Dimensions:
MainUnit:520(l)x370(w)x410(h)mm
BoardHolder:450(l)x280(w)x134(h)mm
Power
Consumption:
Total:2100WattsMaximum
TopHeater:500Watts
BottomHeater:1500Watts
SolderIron:75Watts
TemperatureRange: 50°C280°C(^maximum)
HeatingElement:
TopHeater:ForcedConvectionQuartzInfrared
BottomHeater:QuartzInfrared
SolderIron:Ceramicheater
PreHeatingArea:
TopHeater:60x60mm
BottomHeater:310x310mm
Weight: Approx.11.6Kg
^Dependsontypeofoperatio n
*Specificationssubjectto changewithoutpriornotice
***Expansionforfutureversions,maynotbeavailableforcurrentreleases.
Nozzles
Lamp
Notice***
VacuumSuction
Pen
Others:
Flux.
Spatula.
Temperature
probe
11
OPERATING PROCEDURES
Thistypeofoperationutilizestheexternaltemperatureprobe A toregulate
thetopheater,whiletheexternaltemperatureprobe b regulatesthe heatofthe
bottom heater. Using this type of operation allows us to closely control the
temperature at board level. While freeing up external temperature probe C for
additionalmonitoring.
1. To set the desired top heater temperature press the selection button
repeatedlyuntil the top displayshows “TOP” and the middledisplayshows
“SEt”.Thebottomdisplaywouldshowthecurrentsettemperatureofthetop
heaterfollowedbyasuffix“A”.
2. Press the increase or decrease button to adjust the top heater set
temperaturelevel.Thesettemperatureisadjustablefrom50to280Cinthis
typeofoperation.Totemporarilyturnoffthetopheatersimultaneouslypress
boththe“Increase”and“decrease”button (#3 &#4 fromthecontrolpanel
displaysee page 8) . The bottom display will show “OFF”indicatingthe top
heaterisnowturnedoff.
3. To set the desired bottom heater temperature press the selection button
repeatedly until thetop display shows “bOt” andthe middle display shows
“SEt”. The bottomdisplaywould show the current set temperature of the
bottomheaterfollowedbyasuffix“b”.
4. Press the increase or decrease button to adjust the bottom heater set
temperaturelevel.Thesettemperatureisadjustablefrom50to280Cinthis
typeofoperation.Totemporarilyturnoffthebottomheatersimultaneously
pressboththe“Increase”and“decrease”button (#3 &#4 fromthecontrol
paneldisplayseepage8) .Thebottomdisplaywillshow“OFF”indicatingthe
bottomheaterisnowturnedoff.
5. For this type  (type 1) of operation we must closely monitor the actual
temperature of the Top heater external temperature probe A and the
externaltemperatureprobe b. Asthistwoprobesmanagetheheatofboth
thetopandbottomheater.
