BASIC TROUBLESHOOTING GUIDE
PROBLEM 3: SOLDERING IRON TEMPERATURE IS INTERMITTENT
Description:
Main power LED lights up and so does the heater LED but
soldering iron temperature rises and falls uncontrollably.
SOLUTION:
◆ Soldering iron plug may be loose from the receptacle unplug the
soldering iron and reattach.
◆ Soldering iron cord may be damaged or loose and needs to be
replaced or repaired. See trouble shooting soldering iron cords
section of this manual.
PROBLEM 4: SOLDER WOULD NOT STICK TO THE SOLDERING TIP
Description:
Soldering iron is able to quickly melt solder but cannot cause the
solder to attach to the tip.
SOLUTION:
◆ Soldering iron tip may already be too dirty or oxidized . Please see
our solder tip maintenance guide on how to clean soldering tips.
◆ Temperature could be set too high causing solder to quickly burn
away, Please adjust to a more suitable lower temperature range.
PROBLEM 5: SOLDERING IRON DOES NOT PRODUCE ENOUGH HEAT
Description:
Soldering iron cannot melt solder fast enough, or actual
temperature does not reach the desired set temperature.
SOLUTION:
◆ The system may need to be recalibrated please see
steps in
calibrating the tip temperature
on page 9 of this manual.
◆ Soldering iron tip may already be too dirty or oxidized . Please see
our solder tip maintenance guide on how to clean soldering tips.
5
SPECIFICATION
Model#
Int936A / 936A Int936 / 936
Power Consumption
60W 35W
Fuse
1A 0.5A
MAIN STATION
Output Voltage
24V 24V
Temperature Range
200—480 °C
392—896 °F
200—480 °C
392—896°F
Dimension
110(w)×93(l)
×168(h) mm
110(w)×93(l)
×168(h) mm
SOLDERING IRON
Power Consumption
24V—60W 24V—60W
Tip to Ground
Resistance
Less than 2 Ohm Less than 2 Ohm
Tip to Ground
Potential
Less than 2 Ohm Less than 2 Ohm
Heating Element
PTC Heating
Element
Ceramic Heating
Element
Power Cord
1.1 meters 1.1 meters
Length
1.2 meters 1.2 meters
Weight
108 grams 100 grams
Design and specification might change without prior notice.
