Seat tube battery
(Wakita Tour MX, Wakan Tour MX, Wakita Grace MX, Wakan Grand MX, Wakita Grace, Gaagii, Gaagii Lady,
Wakita Tour, Wakita City, Wakita Prime, Wakan City, Tanka, Tanka Nexus, Tocho, Tocho Nexus)
Switching on: Switch on the battery using the switch in the upper part of the battery.
Handling: To remove the battery eject the saddle tube with the saddle from the frame. The lock is placed in the bottom
part of the battery. Then turn the key to position UNLOCK and remove the battery by pulling it upwards holding the
handle grip. The battery insertion do in the reverse order. Make sure the battery groove meets the guiding bar otherwise
inserting downwards would not work. Insert the battery carefully to prevent from damage by strong impact against the
connector. In order to secure the battery turn the key to position LOCK and remove the key.
Battery charge status indicator: by the help of LED indicator placed in the upper battery part that is activated by
pressing the button. The battery must be switched on. The battery has full capacity if 4 LED diodes light on (3 in green,
1 in red). If only the red diode is on it means the battery is almost empty and it needs to be charged as soon as possible.
battery status
LOCK
UNLOCK
power
switch
Battery charge status indicator: by the help of LED indicator placed in
the upper battery part that is activated by pressing the button. The battery
must be switched on. The battery has full capacity if 4 LED diodes light
on (3 in green, 1 in red). If only the red diode is on it means the battery is
almost empty and it needs to be charged as soon as possible.
Rack battery
(Dakotah, Dakotah Nexus)
Switching on: turn on the switch placed in the rear part of the battery.
Handling: To remove the battery turn the key by 180°. Grasp the battery
by the handle grip placed underneath the battery and pull it out the carrier.
The battery insertion do in the reverse order.
power switch
battery status
13
