6
ERASING TEMPORARY DATA
To erase the temporary data (trip, time, avg, max)
twice push the button
M
. rES will show on the
display. Pick option
M
with buttons
A
and
C
and confirm with button
M
.
PARAMETERS SETTING
To enter the mode of parameter setting press
twice the
M
button. To change a parameter,
use buttons
A
and
C
and for saving the set
parameter press the
M
button.
TURNING ON THE LIGHTING
IF IT IS INSTALLED
Turning on the front and rear light is done by
pushing and holding the
A
button for 1 second.
USB PORT
The display is equipped with a micro USB port
for charging of mobile devices (5V/0,5W).
To connect your device with the charging
connector, use any adapter or cable with Micro
USBB connector.
WALKING ASSISTANT
Walking assistant can be activated by pressing
and holding the
C
button on the control display.
For activation of the assistant assistance mode
must be set to 1-5. This function serves to enable
easier manipulation with e-bike, usually when
walking the bike by your side. The e-bike speed
will be between 4 and 6 km/h. Walking assistant
will be turned off immediately after letting go of
the button.
WARNING: Do not block the e-bike
Lafter the activation of the walking
assistant. The motor can get damaged
that way.
SPEED AND DISTANCE INDICATOR MODE
CHANGE
Change of information displayed on the display
can be done by short press of the button
M
.
Information shows in this order:
rES – reset of daily kilometres
Un – unit setting (km / mile)
Ld – setting of the bike circumference in cm (max. +/- 5 % from the default setting of the circumference)
bL – display backlight setting in 1-3 range
Ls – speed limit; value 20 means max. assisted speed of 25 km/h
SPS – wheel speed sensor signal
Cr – value of the electric current
TRIP
Lenght of the trip
ODO
Total distance
TIME
Time*
MAX
Maximum speed
AVG
Average speed
ERROR
MESSAGES
Code Cause of the problem
0X0000 no error
0X0001 controller power tube or over current
0X0002 controller over heat
0X0004 motor phase
0X0008 motor hall
0X0010 motor over heat
0X020 low voltage protection
0X0040 stall protection
0X0080 throttle
0X0100 over-speed beyond control
0X0200 battery communiction
0X0400 pas sensor
0X0800 speed sensor
0X1000 display communication
If the error remains or a different one shows, contact your seller.
