inputs at the time. Do not connect an unbalanced signal to the
XLR connector when phantom power is present, this will result
in a short circuit of the phantom power supply.
16. Microphone 1 input on DIN5: balanced microphone level
input. This input is internally hardwired to the MIC 1 XLR jack
input (15) and the MIC 1 connector on the front panel of the
unit. Use only one of these inputs at the time. The DIN5 wiring
diagram is shown on the back of the unit and is compatible
with our MICPAT-D and MICPACB-D microphones. MICPAT-D
and MICPACB-D require no phantom power !
17. Chime level control: when the chime/mute contact of
microphone 1 is closed, the chime will sound. Set its level with
this control.
