APART PIR7600 - System Diagram; Utility Room and Meeting Room Setup

AP122
L R
230Volt
230Volt
Power
Distributor
Local Stereo Input
Local MIC Input
IR Remote Control
Wall Control
DOWN
UP
MIC
ONLY
MUTE
IR
Receiver
IR Emitter
LCD Beamer
Amplifier
UTILITY ROOM MEETING ROOM
Source 1
Source 2
Source 3
Source 4
PIR7600
REMOTE CONTROLLED PRE-AMPLIFIER
