3.5.5 The setting of the Baud rate for the RS-232C
Baud rate of RS-232C output can be set.
1. Press “SET”. and then “7” key.
2. Choose the condition with [1]/[2]/[3] keys.
1
11
1:9600bps 2
22
2:19200bps 3
33
3:38400bps
3. Press “SET key.
The condition is fixed and memorized.
Display comes back to “Ready” without memorizing the data
when “EXIT” key is pressed.
3.5.6 The setting of the other RS-232C protocols
Protocols for RS-232C output can be set.
1. Press “SET”, and then “8” key.
2. Choose the condition with [
],[
] keys.
ｄ
ｄｄ
ｄ:Data_bit ｓ
ｓｓ
ｓ:Stop_bit ｐ
ｐｐ
ｐ:Parity
3. Press “SET”, and then “8” key.
Data bit : [
7
](７bit) / [
8
](８bit)
Stop bit : [
1
](１bit) / [
2
](２bit)
Parity : [
1
](ODD) / [
2
](EVEN) / [
4
](NONE)
4. Press “SET key.
The condition is fixed and memorized.
Display comes back to “Ready” without memorizing the data
when “EXIT” key is pressed.
3.5.7 Deletion of data
You can delete the stored data for the designated ID_No..
And “SN._” comes back to “1”.
1. Press “No.” key.
e.g. in case of ID_No. 5, press [NO] then, [5].
2. Press “DEL” key.
3. Press “SET key.
The condition is fixed and memorized.
Display comes back to “Ready” without memorizing the data
when “EXIT” key is pressed.
No.5 ID
No.5 IDNo.5 ID
No.5 ID-
--
-
