DYNAMIC PROCESSORS 7
DESCRIPTION OF CONTROLS
REAR PANEL:
11) Normal/bridge: this switch must be engaged when using a bridged amp (32db gain)
All inputs and outputs are electronically balance: the connectors are 3 pin XLR'S
The mains receptacle is at the EEC standard with the center prong connected to ground. For
obvious safety reasons, it should always be connected.
The SPDS series can be operated continuously; thus they do not have a mains switch.
The SPDS series use a hum loop eliminator.
If any hum or buzz occurs, it is not caused by a ground loop.
The mains fuse must be replaced only with the same type and value
220-240Vac 0,1 A Temp.
100-125Vac 0,2 A Slow-blow
