Apogee AD-1000 - Power Connector Pinout Diagrams

AD-1000 Operating Manual
Page 44
AD-1000 HD15 connector (J1) pin numbering
viewed looking into the connector on the
unit from the outside (numbers are as molded
on the connector itself)
12345
678910
1112131415
J1
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
CHASSIS
GND
+12v rtn (gnd)
+12v (Bat)
S/PDIF
WC UNBAL 75Ω
SHIELD (from PSU)
WHITE (from PSU)
GRAY (from PSU)
(BLACK)
AD-1000 HD15 connections – S/PDIF
SHIELD
SHIELD
