AIM-4SL Terminal Connections
Reader Connections
Position
Type
Label
Function
1
Ground (Reader Power)
GND
Reader 1 Device Connections
2
Green LED Control
GLED
3
Beeper (Buzzer) Control
BZR
4
Wiegand Data 1
D1
5
Wiegand Data 0
D0
6
VDC (Reader Power)
VDC
7
Red LED Control
RLED
8
Yellow LED Control
YLED
9
Auxiliary Input Return
AUXR
Reader 1 Auxiliary Input (Normally
Closed)
10
Auxiliary Input
AUX
11
Exit Push Button Return
EPBR
Reader 1 Exit Push Button
(Normally Open)
12
Exit Push Button
EPB
13
Door Contact Return
DCR
Reader 1 Door Contact
(Normally Closed)
14
Door Contact
DC
15
Ground (Reader Power)
GND
Reader 2 Device Connections
16
Green LED Control
GLED
17
Beeper (Buzzer) Control
BZR
18
Wiegand Data 1
D1
19
Wiegand Data 0
D0
20
VDC (Reader Power)
VDC
21
Red LED Control
RLED
22
Yellow LED Control
YLED
23
Auxiliary Input Return
AUXR
Reader 2 Auxiliary Input (Normally
Closed)
24
Auxiliary Input
AUX
25
Exit Push Button Return
EPBR
Reader 2 Exit Push Button
(Normally Open)
26
Exit Push Button
EPB
27
Door Contact Return
DCR
Reader 2 Door Contact
(Normally Closed)
28
Door Contact
DC
