AIM-4SL Terminal Connections
29
Ground (Reader Power)
GND
Reader 3 Device Connections
30
Green LED Control
GLED
31
Beeper (Buzzer) Control
BZR
32
Wiegand Data 1
D1
33
Wiegand Data 0
D0
34
VDC (Reader Power)
VDC
35
Red LED Control
RLED
36
Yellow LED Control
YLED
37
Auxiliary Input Return
AUXR
Reader 3 Auxiliary Input (Normally
Closed)
38
Auxiliary Input
AUX
39
Exit Push Button Return
EPBR
Reader 3 Exit Push Button
(Normally Open)
40
Exit Push Button
EPB
41
Door Contact Return
DCR
Reader 3 Door Contact
(Normally Closed)
42
Door Contact
DC
43
Ground (Reader Power)
GND
Reader 4 Device Connections
44
Green LED Control
GLED
45
Beeper (Buzzer) Control
BZR
46
Wiegand Data 1
D1
47
Wiegand Data 0
D0
48
VDC (Reader Power)
VDC
49
Red LED Control
RLED
50
Yellow LED Control
YLED
51
Auxiliary Input Return
AUXR
Reader 4 Auxiliary Input (Normally
Closed)
52
Auxiliary Input
AUX
53
Exit Push Button Return
EPBR
Reader 4 Exit Push Button
(Normally Open)
54
Exit Push Button
EPB
55
Door Contact Return
DCR
Reader 4 Door Contact
(Normally Closed)
56
Door Contact
DC
Relay Output Connections
57
Common
C
Door 1 Strike Relay Connection
58
Normally Open
NO
59
Normally Closed
NC
