Apollo AIM-4SL User Manual

8Hardware Layout
© 2011 Apollo Security Inc.
AIM-4SL Terminal Connections
60
Common
C
Door 2 Strike Relay Connection
61
Normally Open
NO
62
Normally Closed
NC
63
Common
C
Door 3 Strike Relay Connection
64
Normally Open
NO
65
Normally Closed
NC
66
Common
C
Door 4 Strike Relay Connection
67
Normally Open
NO
68
Normally Closed
NC
69
Common
C
Door 1 Auxiliary Relay Connection
70
Normally Open
NO
71
Normally Closed
NC
72
Common
C
Door 2 Auxiliary Relay Connection
73
Normally Open
NO
74
Normally Closed
NC
75
Common
C
Door 3 Auxiliary Relay Connection
76
Normally Open
NO
77
Normally Closed
NC
78
Common
C
Door 4 Auxiliary Relay Connection
79
Normally Open
NO
80
Normally Closed
NC
AIM-4SL Device Connections
81
Power Input
VIN
Power Input Connection
82
Ground
GND
83
Tamper Input
TMP
Cabinet Tamper Input (Normally
Closed)
84
Tamper Input Return
GND
85
20 mA loop Signal Out
STRK
ADA-10/11 External Relay Loop
86
20 mA loop Signal Return
RET
87
Receive Data (+)
R+
Serial Communication Connection
88
Receive Data (-)
R-
89
Transmit Data (+)
T+
90
Transmit Data (-)
T-
91
Signal Ground
SG
Table 2.1:
AIM-4SL Terminal Connections.
