Apollo PHANTOM V3 User Manual

26
Screw
number
Screw use/location Size Qty.
8 6 9
4
8 6 9
8
8
8 6 9
4
8 6 9
1
2
3
4
5
6
7
8
9
10
11
13
14
15
16
17
18
12
M4 x 8
1
Fender bracket V3
Front Cover/Front plate/Rear Covers/Rear plate
Front Cover/Front plate/Rear Covers/Rear plate
Folding hook/Side Plastic covers
Hydraulic brake lock screw
Throttle screw
Top plate
Display to bracket screw/Kickstand/brake handles
Rocker arm and brake/Handlebar Block
Front locking screw
Front set screw
Under body controller screws
Folding mechanism front tube/Underside Front
Main direction bolt M12
Main direction bolt M14
Main direction bolt M12
Main direction washer M14
Front and rear wheel nut
ST3.5 x 10
M4 x 10
M4 x 6
M6 x 16
M4 x 12
M5 x 10
M5 x 16
M5 x 20
M5 x 30
M5 x 16
M6 x 12
M6 x 20
M12 x 45
M14 x 45
M12
M14
M14 x 1.5
1
1
1
1
1
2
1
1
1
1
2
1
1
1
1
1
1

Apollo PHANTOM V3 Specifications

General

Brakes	Hydraulic disc brakes
Water Resistance	IP54
Tires	10-inch pneumatic
Lights	Front and rear LED lights
Max Load	120 kg
Weight	77 lbs (35 kg)
