Apollo RPLF4A User Manual

32
Customer Service (704) 841-6000
www.apolloflowcontrols.com
“Apl”
Flow Controls
INSTALLATION, OPERATION & MAINTENANCE
MANUAL
10"
TYPE 2
BYPASS
LINE
Adjustment Joint Retainer
Adjustment Joint Nut
Adjustment Joint Adapter
Adjustment Joint O-ring
Test Cock
Rubber Washer
2 each
Water Meter
Meter Nut
1/2" Single
Check Valve
3/4" Male NPT X
1/2" Female NPT Fitting
1/2" Coupling
1/2" 90° Elbow
1/2" 45° Elbow
1/2" Ball Valve
with Tapped Port
(Note Location of Port)
1/2" X 3" Long Nipple
1/2" X 2-1/2"
Long Nipple
1/2" X 6" Long Nipple
1/2" X 4-1/2" Long Nipple
1/2" X 3" Long Nipple
1/2" X 2"
Long Nipple
APPLY TEFLON TAPE TO PIPE
THREADS AND INSTALL
COMPONENTS AS SHOWN.
APPLY TEFLON TAPE TO PIPE
THREADS AND INSTALL
COMPONENTS AS SHOWN.
BYPASS KITS
