Apollo Twin User Manual

Apollo Twin Hardware Manual Chapter 4: Specifications 30
Hardware Block Diagram
APOLLO TWIN HARDWARE BLOCK DIAGRAM V05
HI-Z IN
+48V
MIC IN 1
MIC PAD
IN/OUT
+48V ON/OFF
INPUT GAIN
10 – 65 dB
ANALOG INPUTS
PAD
1M
HI-Z/MIC
SELECT
A/D
LINE IN 1
PAD
D/A
+4dBu / -10dBV
SELECT
ANALOG OUTPUTS
PAD
LINE OUT 3
D/A
MON OUT L
D/A HEADPHONES OUT
SHARC®
DSP
DRAM
SHARC®
DSP
DRAM
ARM®
PROCESSOR
XLR FEMALE
1/4”
1/4” TRS
1/4” TRS 1/4” TRS 1/4” TRS
MIXER
CLOCKING / SYNC
SYSTEM CONTROL
ø
LOW-CUT
ON/OFF
POLARITY
CONTROL
OPTO
OUTPUT
VOLUME
HI-Z/MIC-LINE
SELECT
OPTICAL INPUT
FRONT PANEL
THUNDERBOLT
TM
HOST INTERFACE
+48V
MIC IN 2
MIC PAD
IN/OUT
+48V ON/OFF
INPUT GAIN
10 – 65 dB
PAD
A/D
XLR FEMALE
LINE IN 2
PAD
1/4” TRS
ø
LOW-CUT
ON/OFF
POLARITY
CONTROL
MIC/LINE
SELECT
DSP DSP
+14dBu / +20dBu
SELECT
PAD
D/A
MON OUT R
1/4” TRS
OUTPUT
VOLUME
PAD
D/A PAD
LINE OUT 4
1/4” TRS
D/A
EEPROM
+4dBu / -10dBV
SELECT
+14dBu / +20dBu
SELECT

Apollo Twin Specifications

General

Type	Audio Interface
Phantom Power	Yes
Bit Depth	24-bit
Connectivity	Thunderbolt
Inputs	2 x XLR/TRS combo
Sample Rate	Up to 192kHz
