103N / 105N / 106
EN
The sensitivity in the Hz mode is 1/10 of full scale range.
The accuracy is same as Frequency mode. The measuring
frequency is from 40Hz up to 1KHz.
This instrument has been designed and tested in
accordance with IEC Publication 1010, Safety Requirements
for Electronic Measuring Apparatus and has been supplied
in a safe condition. This instruction manual contains some
Information and warnings which have to be followed by the
user to ensure safe operation and to retain the instrument in
safe condition.
1. Before measurement, warm up for at least 60 seconds.
2. When the rotary function selector is changed during
measurement, be sure do so only after removing the test
leads from
the equipment.
3. If the equipment is used near noise generating equipment,
be aware that may become unstable or indicate large errors.
4.
Maximum rated voltage to earth for voltage and current
measurements terminals is 1000V CAT.II, 600V CAT.III .
1. Connect the red test lead to the “
VΩHz” input terminal
and the other (black) test lead to the “COM” terminal.
2. Set the rotary function to the VA position.
3. Measurement of AC voltage can be performed by pushing
the “BLUE” key switch.
TO AVIOD ELECTRICAL SHOCK, HAZARD OR
DAMAGE TO METER, DO NOT A ATTEMPT TO
MEASURE VOLTAGE THAT MIGHT EXCEED 1000V
ms. DO NOT APPLY MORE THAN 1000V rms
BETWEEN THE COMMON INPUT TERMINAL AND
EARTH GROUND.
(15) Hz Sensitivity
OPERATION
3-1 Preparation and Caution before Measurement
3-2 Voltage Measurements
WARNING
To Next Page
