1
Introduction
1.1 Unpacking and checking
Upon removing your new RC Meterplus from its packing, you should have the following items:
1. RC meterplus.
2. Test leads set (one black and one red).
3. Operating manual.
4. Protective holster.
1.2 Front Panel
Refer to Figure 1 and the following nunberes steps to familiarize yourself with the meter’s front panel controls
and connectors.
1. Digital display — The 31⁄2 segment 1999-count digital LCD display has automatic annunciators for polarity,
decimal point, over range and low battery voltage.
2. Zero adjuster for capacitance — This allows the display to be zeroed when measuring capacitance (zeroing
range approx. ± 20pF).
3. On/off switch — Use this switch to switch the tester "ON" and "OFF".
