4. Rotary function and range switch — This switch is used to set the desired function and range.
5. Capacitance sockets — The terminals of capacitors can be inserted in these sockets to allow their capacitance
to be measured directly.
6. Capacitance input terminal (+) — Positive input for capacitance measurements. Takes banana plug.
7. Capacitance input terminal (-) — Negative input for capacitance measurements. Takes banana plug.
8. Ω, E, D, LED input terminal (+) — Positive output for testing resistors, diodes and LEDs and positive input for
battery testing. Takes banana plug.
9. Ω, E, D, LED input terminal (-) — Negative output for testing resistors, diodes and LEDs and negative input for
battery testing. Takes banana plug.
10. Transistor and SCR socket for transistors and silicon-controlled rectifiers - and for measuring transistor
hFE and I
CEO
and for testing SCRs.
