8
(5) Transistor hFE Test, Trainsistor Leakage Iceo Test
0 - 1000 hFE values either PNP or NPN transistor
hFE Base Current : 10µA approx.
hFE Vce : 3V approx.
Iceo : 10nA - 20.00µA.
(6) SCR Test
SCR good/defect test.
(7) Battery testing
Battery type Load
9V Battery Load. 15mA approx.
1.5V AA, C or D Cell Load: approx. 150mA
1.55V Button Cells Load: approx. 0.8mA
Display reading is battery Voltage approx.
