Connecting Remote Antennas to Stratus 3
WARNING: Make sure that you connect the antenna to the correct
Stratus 3 port� Inserting an antenna connector into an incorrect port may
result in permanent damage to the port or the antenna�
WARNING: Do not pinch or bend the external GPS cable, especially
near the antenna� This could damage the cable and cause interference
between the antenna and other on-board GPS receivers� The cable’s
minimum bend radius is 1 inch�
The ports labeled GPS and ADS-B on the side of Stratus 3 are for remote
antennas� Insert the remote antenna cable connector into its respective
receiver port�
Remote antenna ports
