iMac (21.5-inch, Late 2009) Take Apart — Optical Drive Pressure Wall 211
2010-11-18
First Steps
Note: The optical drive
pressure wall does not
need to be removed.
Remove:
• Glass Panel
• LCD Panel
• Power Supply
• Backlight Pressure Wall
• Power Supply Pressure
Wall
• Optical Drive
• Optical Drive Fan
• IR Board
• Logic Board
Tools
• ESD wrist strap
Optical Drive Pressure Wall
