Introduction
This is the read-me file for the documentation of the Mac-based Cabernet rework
(version 1.1) software. This documentation should be used in conjunction with the ADI
Cabernet service manual. Refer to the appendix A for descriptions on the available
software features and functions in this rework software.
Hardware Requirements
1. Power PC with PCI slot and serial ports.
2. ADS USB card.
3. Quantum 801GF with Mac serial cable connected to serial printer port.
4. Minolta CA100 with Mac serial cable connected to serial modem port.
5. 28V DC power brick with ADC to VGA/USB adapter board.
6. Multi-meter
7. Helmholtz cage.
8. Hand degausser.
9. Insulated alignment tools.
Hardware Setup
Mac CPU
Power Brick
801 GF
Minolta CA100
To Next Page
