7. Specifications
CSP-P Capacitor Discharge Power Supplies
Models Available
CSP-P
:
1500J/s at up to 350J/shot.
Physical Specifications
CSP-P
Size
:
19" Rack Mount 4U high excluding shock mount
housing.
Weight
:
22 kg (Supply Only)
Electrical Specifications
Mains Input : 207 - 260 V 1 phase.
: 45 - 65 Hz @ 2.5 kVA.
*
: 3-Pin connector.
Voltage Output : 2700 to 4000 volts DC.
Output Power : 50 to 350J
By 4-Pin connector (Power and interlock).
Selection : Rotary switches.
Trigger : +ve key (+5 to 25V rising edge) opto isolated or contact closure.
Set by front panel switch.
Discharge Method : Semiconductor module.
Maximum Current : A current sensor ensures that the unit shuts down beyond
approximately 4000 Amps although the thyristor module can
exceed this.
Remote : 10 way Amphenol.
Earth : M8 stainless stud on front panel.
* SEE TEXT ABOUT GENERATOR SELECTION. 110 VOLT VERSIONS ARE AVAILABLE.
